Product description:
The 18650 battery spot welding machine is suitable for automatic welder battery pack spot welding of nickel strips in cylindrical battery pack. Through manual loading and simple settings, it can weld both sides together with high speed and good effect.
Scope of application:
The double-sides spot welding machine for battery pack, it is suitable for 18650/ 21700/ 26650/ 32650 power battery, electric bicycle batteries, energy storage battery…
Characteristic:
1. Welding effect: good welding consistency, uniform welding points, beautiful.
2. The spot welder machine has the function of storing 200 sets of spot welding parameters, which can quickly switch the spot welding mode.
3. High welding efficiency: about 4000~5000PCS / hour.
4. The spot welder for battery comes with a fault alarm; clear the fault according to the prompt.
5. We can provide different welding machines according to the different requirements of customers to effectively meet the needs of customers.
Device parameters
|
Name |
Automatic Battery Double-sides Spot Welding Machine |
|
Model |
WA-SW-200T |
|
Power supply |
220V±10% / 50Hz±10% |
|
Power |
6000 W |
|
Air pressure |
0.4~0.8MPa |
|
Thickness of flat welding nickel sheet |
0.1~0.3MM (The thickness of 0.21~0.3MM requires slotted nickel) |
|
Production efficiency |
4000~5000PCS/Hour |
|
Y-axis travel |
35PCS 18650 battery cells (Customizable) |
|
Z-axis travel |
20PCS 18650 battery cells (Customizable) |
|
Welding source |
Need to be allocated |
|
Control component |
10-inch touch screen 6-axis high speed PLC programmer 3-axis 750W servo motor 2-axis 400W servo motor drive electric welding head |
|
Operating system |
Embedded motion control system & human-machine interface |
|
Size(L*W*H) |
1630*850*1630mm |
|
Weight |
About 220kg |
Equipment configuration
|
Serial number |
Spare parts |
Brand |
|
1 |
Servo motor |
XINJIE |
|
2 |
Welding host |
Miyachi |
|
3 |
Touch screen |
XINJIE |
|
4 |
PLC |
XINJIE |
|
5 |
SMPS |
Hepu |
|
6 |
Ballscrew |
Taiwan |
|
7 |
Sliding block |
Taiwan |
|
8 |
Pneumatic element |
Taiwan |
|
9 |
Alarm system |
Taiwan |
